C031-3S Serpentine-Flow Raman Cell

Product overview

The C031-3S adds a serpentine gas path to the C031-3 Raman-cell arrangement. This is a distinct flow-field configuration, rather than another name for the straight-channel model. The catalog specifies a 37 mm optical window and a working surface less than 6 mm below it. Define the gas-diffusion electrode and optical clearance together when requesting this version.

Specifications & ordering details

Use these parameters to define your requirement. The quotation confirms the exact supplied specification.

Material / system	Gas-diffusion Raman arrangement; optical window
Catalog model	C031-3S
Gas path	Serpentine channel
Optical window diameter	37 mm
Standard working area	1 cm²
Working-electrode-to-window distance	Less than 6 mm
Instrument and optical / beam geometry	Specify with your requirement.
Sample, electrode and window requirements	Specify with your requirement.
Connections and included accessories	Specify with your requirement.

Research applications

Gas-diffusion Raman electrochemistry
Serpentine flow-field studies
In-situ catalyst observation

Before you order

Specify C031-3S rather than C031-3.
Provide the electrode, membrane and gas connection requirements.
Confirm objective clearance and the supplied electrode scope.

Product documents

View the source catalog for this offering. Share your instrument model, configuration and application to request the relevant specification or material documentation.

View Electrochemistry, Flow & MEA Systems — page 7 ↗Download PDF

Selection questions

How do I check the instrument interface?

Share the instrument make and model, sample geometry, optical or beam path, mounting arrangement and drawings. The cell and instrument interfaces must be reviewed together.

Which experimental conditions are needed?

Specify temperature, pressure, atmosphere or electrolyte, and electrical connections. Confirm sample access, windows, fittings and accessories for the selected method.
