UV2600-2 H-Type UV Electrochemical Cell

Product overview

The UV2600-2 changes the single-chamber UV2600-1 arrangement to an H-type divided cell. The catalog distinguishes a replaceable diaphragm and gas inlet/outlet connections on the working-electrode chamber. Define membrane dimensions, gas connections and optical access as one configuration. Specifications shown only for the UV2600-1 should be confirmed for the selected UV2600-2 assembly rather than assumed identical.

Specifications & ordering details

Use these parameters to define your requirement. The quotation confirms the exact supplied specification.

Material / system	H-type divided UV cell with replaceable diaphragm
Catalog model	UV2600-2
Cell configuration	H-type dual chamber
Separation	Replaceable diaphragm
Gas connections	Inlet and outlet on the working chamber
Optical instrument fit	Confirm for the selected cell and spectrophotometer
Active area and flow-field design	Specify with your requirement.
Plate / current-collector materials	Specify with your requirement.
Connections and included accessories	Specify with your requirement.

Research applications

Divided-cell UV spectroelectrochemistry
Gas-fed working-chamber experiments
Membrane-separated electrode studies

Before you order

Specify the diaphragm or membrane material and dimensions.
Provide gas inlet/outlet fitting requirements.
Confirm body/window materials, electrode scope and optical fit for this configuration.

Product documents

View the source catalog for this offering. Share your instrument model, configuration and application to request the relevant specification or material documentation.

View Electrochemistry, Flow & MEA Systems — page 17 ↗Download PDF

Selection questions

What should a custom enquiry include?

For UV2600-2 H-Type UV Electrochemical Cell, provide the active area, sample or electrode geometry, materials, interfaces and the operating conditions. Include drawings and identify every component in the assembly scope.

Are electrodes, membranes and accessories included?

Specify the parts required. Hardware, membranes, electrodes, gaskets, fittings and instruments should be identified separately in the quotation.
